SVAT ELECTRONICS
Model #:
CLEARVU4
www.svat.com
SVAT, CLEARVU and “now you can see” are
trademarks of SVAT Electronics.
©2007 SVAT Electronics
All Rights Reserved
SPECIFICATIONS (for more detailed specifications visit www.svat.com)
INDOOR DVR
Functionality
..............................................Simplex
Video Compression
.................................MJPEG
Live Resolution
..........................................NTSC : 704 X 480 / PAL: 704 X 576
Recording Frame Rate
............................30FPS
Recording Time
.........................................750 Days (0.5 Frames Per Second)
Recording Qualities
.................................Low/Medium/High
Storage Capacity
.......................................Max 500GB (HDD), 320GB included
Video Format
.............................................NTSC/PAL
Live Display
.................................................Single / Quad / 9-Split / 16-Split
Network LAN IP
.........................................Dynamic, Static
Network Connection
...............................10/100 BaseT Ethernet (RJ-45)
Back-up
........................................................CF Card, Max 4GB
Play Search Mode
.....................................Time/Date, Event List
OSD Language Display
...........................Multi-Language
Time and Date Stamp Display
.............Yes
Password Protection................................Yes, Menu Password
File Transfer
.................................................CF Card, Max 4GB
Operating System.....................................Proprietary
Automatic Overwrite Option
...............Yes
Power Input
................................................12V/4.2A
OUTDOOR CAMERA (CV67)
Camera Type
...............................................Bullet
Image Sensor
.............................................1/4" Color Sharp CCD
Resolution
...................................................420 TV Lines
IP Rating
.......................................................IP65
Focal Length
...............................................3.6mm
Focus Type
..................................................Fixed
Night Vision
................................................Yes
Number of IR LEDs and Range
.............12, up to 15ft
IR LED Control
............................................Automatic (CDS Sensor)
Min. Illumination
.......................................0 lux
Video Output
.............................................60ft 4 PIN DIN to RCA Video/Power Wire
TV System
....................................................NTSC
Viewing Angle
...........................................60 Degrees
Housing Material
......................................Anodized Aluminum
Operating Temperature
.........................-14°F ~ 122°F
Camera Power Input
................................DC 12V 300mA
DIMENSIONS
DVR: 16.94" x 11.63" x 2.63" ~ 8.85lbs
Camera: 5.5" x 5" x 2.44" ~ 0.85lbs
WHAT IS COMPATIBLE WITH THIS SYSTEM?
The CLEARVU4 is compatible with TVs, computers, all SVAT cameras with RCA outputs and other
SVAT systems including:
WHAT IS INCLUDED WITH THIS SYSTEM?
UPC #
CLEARVU4 ~ 871363006585
1 DVR
(320GB HDD)
16 Outdoor Night
Vision Cameras
1 10ft RCA to
RCA (male)
A/V Wire
10ft RJ-45
Ethernet Cable
Software CD
CV67 CV31 CCDCO CMOSCO Extension Wires
• 18 RCA to BNC Connectors
•1 Power Adapter for DVR
•16 Power Adapters for Cameras
• 1 Year Warranty
• Quick Start Guide
• Instruction Manual
• 8 Window Warning Stickers
• Online/Toll Free Support
Web Ready 16CH DVR System w/ 16 Outdoor Night Vision CCD Color Cameras
16x 60ft 4 PIN DIN
to RCA (male)
Video/Power Wires
SVAT Electronics
Toll Free: 1.866.946.7828
now you can see
WHERE DO I USE THIS?
At home to watch your:
• Garage • Backyard
• Property • Driveway
At work to watch your:
• Entrance Ways • Employees
• Parking Lot • Warehouse
16 CHANNEL DVR RECORDER
1. LED Indicator - Power, HDD Activity
2 Removable/Lockable HDD Casing:
3. Camera Channel Select (1-8)
4. Record Button
5. Stop Button
6. Play Button
7. Pause Button
8. Split Button
9. Auto Sequencing Button
10. Search Button
11. Menu Button
12. Exit/Info Button
13. Enter/Display Button
14. CF Card Slot
15. Left Button
16. Right Button
17. Up Button
18. Down Button
19. LED Indicators
20. BNC Video Inputs
21. DC power input (12V).
22. Alarm Input/Output Port
23. Audio Input
24. RCA Audio Outputs
25. BNC Video Output
26. Ethernet Port
27. BNC Spot Video Output
28. Cooling Fan
CCD CAMERAS
29. Sun Shield
30. Infrared (IR) LEDs
.31. CDS Sensor
32. Camera Housing
33. Camera Mount
34. Connection to Video/Power Wire
NOTE: Product May Appear Different Than Shown
.
60ft Extension Wire
Ends on the 60ft extension wire.
Power (red), & Video (yellow)
RCA to BNC Connector
Connects RCA cameras to the
video inputon the back of the DVR
320GB 16CH DVR RECORDING CHART
0.5 1 2 4 7.5 15 30
750 375 150 180 95 25 12
650 325 130 65 35 15 8
375 185 90 45 25 12 6
Low (days)
Med (days)
High (days)
QUALITY
FRAME RATE PER SEC.
www
Access your DVR
from anywhere
in the world
CV67 Cameras Do Not Support Audio
