Chapter 4: Installing Components
www.gateway.com
Replacing the case fan
To replace the case fan:
1 Follow the instructions in “Preventing static electricity discharge” on
page 25.
2 Follow the instructions in “Opening the server case” on page 26.
3 Unplug the case fan from the system board.
4 Use a narrow tool, such as a small screwdriver, to push each of the four
fan mounting rivets and sleeves out toward the back of the case.
Rear fan connector
