6
Parts of the Camera
Introduction
The Monitor
The following indicators may appear in the monitor during shooting and playback
(actual display varies with current camera settings).
The indicators and photo info displayed during shooting and playback will turn off
after a few seconds (A 103).
Shooting
* Differs according to the current shooting mode. Refer to the sections on each mode for
details.
9999
9999
10
10
+1.0
+1.0
8
9
10
11
14
1516
17
18
19
20
13
4
2
5
6
7
21
12
13
1
Shooting mode*
..................................................22, 35, 36, 42, 60
2 Macro mode....................................................33
3 Zoom indicator......................................25, 33
4 Focus indicator..............................................26
5 Flash mode.......................................................30
6 Flash indicator................................................31
7 Internal memory indicator......................23
8 Battery level indicator................................22
9 ISO sensitivity..........................................31, 88
10 Vibration reduction icon.......................105
11 Self-timer indicator......................................32
12
“Date not set” indicator..........................117
Time zone indicator.................................100
13 Date imprint..................................................104
14
Number of exposures remaining
(still pictures)...................................................22
Movie length...................................................60
15 Focus area.................................................26, 89
16 Focus area (Face Priority) ........................42
17 Exposure compensation value............34
18 Image mode....................................................83
19 Color options..................................................88
20 White balance mode..................................85
21 Continuous shooting mode..................87
