C3432M-F (6/08) 37
Specifications
GENERAL
Pan/Tilt Adjustment Manual
Pan 360°
Tilt 80° (20° to 100° range)
Rotation 360°
Construction Aluminum with steel camera mounting bracket and polycarbonate dome
Cable Entry One 0.75-inch (1.91 cm) NPT threaded opening on side; two 0.75-inch
(1.91 cm) openings on NEMA cover
Finish Gray polyester powder coat
Light Attenuation
Smoked f/1.5 light loss
Clear Zero light loss
Unit Weight 2.2 lb (1.0 kg)
ELECTRICAL
Ports RJ-45 connector for 100Base-TX
Auto MDI/MDI-X
Autonegotiate/Manual setting
Cabling Type Cat5 or better for 100Base-TX
Input Voltage 24 VAC (18-36) or PoE (IEEE802.3af)
Power Consumption <7.5 W, <13 W with heaters
24VAC: <0.5 A, <0.9 A with heaters
Alarm Input 10 VDC maximum, 5mA maximum
Alarm Output 0 to 15 VDC maximum, 75 mA maximum
Service Connector Internal to housing 3-connector, 2.5 mm connector providing NTSC/PAL
video outputs
VIDEO
Signal System NTSC or PAL
Compression MPEG-4, MJPEG in Web viewing mode
Video Streams 3, simultaneous
Video Resolutions NTSC
PAL
4CIF 704 x 480 704 x 576
2CIF 704 x 240 704 x 288
CIF 352 x 240 352 x 288
QCIF 176 x 120 176 x 144
Bit Rate Configurable 20 kbps to 2 Mpbs per stream, implements EnduraView
™
Video Access form
Web Browser Camera live view for up to 10 video sources
Users 10 simultaneous users, unlimited number of users using multicast
Minimum Web Browser
Requirements PC (Pentium
®
4 microprocessor, 1.6 GHz) with Windows
®
98,
Windows 2000, Windows XP (or later) or Mac
®
OS X 10.3.9 (or later)
RAM 512 Mbyte
Ethernet Card 100 Mbit
Web Browser Internet Explorer 5.5 (or later) or Firefox 1.5 (or later)
Screen Resolution 1024 x 768 pixels or higher, 16- or 32-bit pixel color resolution
