CAUTION:
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
IMPORTANT SAFEGUARDS AND WARNINGS
Observe the following WARNINGS before installing and using this product.
1. Installation and servicing should be done only by qualified service personnel and conform to all local codes.
2. Only use replacement parts Pelco recommends.
3. The installation method and materials should be capable of supporting four times the weight of the enclosure, pan and
tilt, camera and lens combination.
4. The camera and lens combination shall not exceed 20 lb (9.06 kg).
5. For marine applications, the installation shall be in accordance with the Electrical Engineering Regulations of the USCG,
Subpart J, C.G. 259 (46 CFR Parts 110-113).
6. This enclosure has not been evaluated for use on vessels less than 65 feet (19.81 m) long.
7. Thermal shock of window was conducted at 83°C. If the temperature of the window is greater than 73°C in the end
product, the thermal shock test must be repeated.
8. Connection facilities must be provided as part of the end product.
9. External or internal grounding connection must be provided for a minimum size conductor of 1.02 mm
2
(18 AWG).
10. Earthing or bonding facility for equipotential conductor should be provided inside the terminal compartment near the
other connection facilities.
11. An EEx d IIB stopping box or cable gland must be provided as part of the end product.
12. When included in an end use installation, it must conform to the ATEX requirements.
The product and/or manual may bear the following marks:
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within this unit.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
Please thoroughly familiarize yourself with the information in this manual prior to installation and operation.
