MDR6 Features
The Samson MDR6, six channel mixer, is a comprehensive, all-in-one solution for live sound, recording, fixed installation
and post production applications. Here are some of its main features:
• Six channels – Two Mic/Line plus two Stereo inputs with mic pre’s.
• Flexible design topology ideal for live sound, recording and post production.
• Unique monitoring and bussing in HDM (HARD DISK MODE) provides a seamless interface with computer
based, hard disk recording systems.
• 60 mm audio taper faders on all channels and the master Mix outputs.
• 2TK LEVEL control allows you to mix in a CD, DAT, Cassette, Computer Sound Card or Mini Disk.
• Three-band channel equalizer, +/-15dB at 80Hz, 2.5 KHz and 12KHz provides precise and musical results in
sound shaping.
• An Auxiliary Send for external effects, on stage monitor mix, or headphone mixing.
• Five segment LED Meter with VU ballistics displays the main MIX output.
• High quality, low noise, discrete microphone pre-amplifiers with 48-Volt phantom power, provide Maximum
Dynamic Range and transparent audio.
• Advanced circuit design using discrete components and high quality, low noise op-amps carefully selected at
each stage of the signal path.
• Quality built and rugged construction ensure reliable performance from venue to venue and session to session.
• Three-year extended warranty.
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
�
