5-3 Details of Functions
Chapter 5 Using the Utility Software
3 In the confirmation message box, click
the OK button.
4 Exit the utility software (see page 46).
5 Do one of the following on the or
icon displayed in the remote
computer’s taskbar.
• Double click.
• Right click, and select one of the
following commands from the menu
which appears.
- Windows 2000: Unplug or eject
hardware
- Windows XP: Safely Remove
Hardware
• Windows 2000: The Unplug or
Eject Hardware dialog appears.
• Windows XP: The Safely Remove
Hardware dialog appears.
6 Select “Sony XDCAM PDW-D1 IEEE
1394 SBP2 Device” and click Stop.
The Stop a Hardware device dialog
appears.
7 Select “Sony XDCAM PDW-D1 IEEE
1394 SBP2 Device” and click OK.
• Windows 2000: A confirmation
message appears.
• Windows XP: “Sony XDCAM
PDW-D1 IEEE 1394 SBP2 Device”
is deleted from the Hardware
devices list.
8 Power the unit off, and then power it
on again.
The line mode selected in step 1
becomes available for use.
Owner setting
When using an extended UMID, set the
following owner information.
Country code
You can find your own country code on the
following web page.
Refer to ISO 3166-1:
http://www.evertype.com/standards/
iso3166/iso3166-1-en.html
Organization code
• Organization codes must be acquired by
applying to the SMPTE registration
office.
• When no organization code has been
acquired, it is forbidden to enter an
arbitrary string. As a rule, the code “00”
must be entered. Freelance operators who
do not belong to an origination should
enter “
~
.”
• There are no problems in recording or
playing back audio-video signals, if an
organization code is not set.
User code
• The user code is registered with each
organization locally. It is usually not
centrally registered.
• This user code is determined by the
organization. The methods used depend
on the organization.
• User code cannot be entered when no
organization code has been entered.
Item name Settings
Country code An abbreviated
alphanumeric string (up
to four bytes
alphanumeric strings)
according to the values
defined in ISO 3166-1.
Organization
code
A code registered with
the SMPTE registration
office (up to four bytes
alphanumeric strings)
User code A code for user
identification (up to four
bytes alphanumeric
strings)
