Retinal Camera
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1 Digital camera
2 Digital camera cover
3 Observation monitor
For viewing the anterior eye and retina.
4 Power switch for the digital camera
5 Operation lever
6 Shutter release button
7 Alignment button
Switches between a view of the anterior eye and
the retina.
8 Main unit vertical movement ring
Turn right: Main unit moves up.
Turn left: Main unit moves down.
9 Focus ring
Turn to focus the image.
10 Stage lock
11 Indentation for lifting
12 Height adjustment mark
13 Main unit
14 Operation panel
15 USB connector
16 AC power connector
17 Power switch for main unit
18 Stage
3
Names of Parts
