23
Hard Disk Security Submenu of the Security Menu
The Hard Disk Security submenu is for configuring hard disk security features.
Figure 15. Hard Disk Security Submenu
Table 15: Fields, Options and Defaults for the Hard Disk Security Submenu of the Security Menu
Menu Field Options Default Description
Drive0:
___
Clear Display-only. Default is Clear. When the Drive0 Password has been set, the field
changes to Set. When this password is set, the primary hard disk drive cannot be
used in another system unless the password is entered.
Set Master
Password
___
[Enter] Sets, changes or cancels the Drive0 Master Password. The Drive0 Master Password
may be up to 32 characters long and must include only letters or numbers (no sym-
bols). Passwords are NOT case-sensitive. Note that the password will not take effect
until the system has been rebooted.
Set User Password
___
[Enter] Sets, changes or cancels the Drive0 User Password. The Drive0 User Password may
be up to 32 characters long and must include only letters or numbers (no symbols).
Passwords are NOT case-sensitive. When a Drive0 User Password is set, it must be
used to access the modular hard drive if it is used in another system.
Password Entry on
Boot:
■
Disabled
■
Enabled
[Enabled] When set to disabled, entry of a Hard Disk Password is not required before OS boot.
(The hard disk is still password-protected without password entry.)
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Item Specific HelpHard Disk Security
Drive0: Clear
Set Master Password [Enter]
Set User Password [Enter]
Password Entry on Boot: [Enabled]
Phoenix SecureCore(tm) Setup Utility
Info System Advanced Security Boot Exit
*Hard Disk Password cannot be set or changed
if the system is rebooted from OS. Choose "Save
Changes and Power Off" in Exit Menu to shut down
the system, then Hard Disk Password can be set
or changed on next boot.
Security Menu
