Miscellaneous Configurations Submenu of the Advanced Menu
The Miscellaneous Configurations Submenu provides options for enabling or disabling the power button and the
Wake Up On LAN or USB features, and for setting the volume.
Figure 10. Miscellaneous Configurations Submenu
Table 10: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of the Advanced
Menu
Menu Field Options Default Description
Power Button:
■
Disabled
■
Power Off
[Disabled] Selecting Disabled disables the power button. Selecting Power Off allows you to
turn off system power with the power button.
Wake up on LAN:
■
Disabled
■
Enabled
[Disabled] Selecting Enabled allows the system to wake up when the internal LAN device
receives a signal while in power-off state. Select Disabled to disables the feature.
Force LAN Boot:
■
Disabled
■
Enabled
[Disabled] This is only active when Wake up on Lan: is enabled. When enabled, the system
will attempt to boot up from the LAN before attempting to boot from any other
device. This occurs regardless of the BIOS boot priority settings or if Preboot
Execution Environment is disabled.
Volume Setting:
■
Off
■
Minimum
■
Middle
■
Maximum
[Middle] Allows you to set or disable the system volume level.
Note that once the operating system initializes, the volume settings will be
determined by the OS volume settings.
UMA Video
Memory Size:
■
64MB
■
128MB
■
224MB
[128MB] Maximum size allocated for shared video memory. Video memory is dynamically
allocated as needed by Intel(R) Dynamic Video Memory Technology (DVMT).
F1 Help
ESC Exit
Select Item
Select Menu
-/Space
Enter
F9 Setup Defaults
F10 Save and Exit
Change Values
Select Sub-Menu
▲
Main Advanced Security Power Savings Exit
Item Specific Help
PhoenixBIOS Setup Utility
Configures the power
button.
*ACPI OS ignores this
setting.
Miscellaneous Configurations
Power Button:
Wake up on LAN:
Force LAN Boot:
Volume Setting: [Middle]
UMA Video Memory Size: [128MB]
[Disabled]
[Disabled]
[Disabled]
Advanced Menu
