ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS
The Advanced Menu allows you to:
■
Set the keyboard and mouse features.
■
Select between the display panel and an external CRT
display or video projector.
■
Enable or disable compensation for your display.
■
Enables or disables the internal controllers.
■
Configure CPU and USB features in your system.
Follow the instructions for Navigating Through the
Setup Utility to make any changes.
The following tables show the names of the menu fields
for the Advanced Menu and its submenus, all of the
options for each field, the default settings and a descrip-
tion of the field’s function and any special information
needed to help understand the field’s use.
Figure 4. Advanced Menu
Table 4: Fields, Options and Defaults for the Advanced Menu
Menu Field Description
Keyboard/Mouse Features When selected, opens the Keyboard/Mouse Features submenu, which allows turning NumLock on or off.
Video Features When selected, opens the Video Features submenu, which allows setting of the display parameters,
including routing of video signals to different displays.
Internal Device
Configurations
When selected, opens the Internal Device Configuration submenu, which allows enabling or disabling the
Serial ATA, IDE, and LAN Controllers.
CPU Features When selected, opens the CPU Features submenu to allow you to enable or disable the SpeedStep® Tech-
nology feature and XD Bit functionality.
USB Features When selected, opens the USB Features submenu to allow you to enable or disable the legacy support and
SCSI SubClass support (e.g., floppy disk drive, external optical drive).
