AirLink MP595 / MP595W Modem User Guide

24 2130795

· 1900MHz(PCS)

· 800MHz(Cellular)

Youcanuseadual‐bandantennathatsupportsbothfre‐

quencies.IfyourMPmodemwillonlybeconnectedtonet‐

worksthatuseoneofthebands,anappropriatesingle‐

bandantennaissufficient.Contactyourserviceprovider

forinformationaboutradio bandsusedinyourarea.

• Accesspointantenna.The2.4GHzAPantennaconnectsto

theAPantennaconnectorontherearoftheMPmodem.

Formoreinformationaboutantennasforyourinstallation

contactyouraccountmanager.

GPS antenna

TheGPSantennaconnectstotheMPmodemusingamale

SMAconnector.Contactyouraccountmanagerformoreinfor

‐

mationaboutcompatibleGPSantennas.

MP 595880W only)

TheAPantennamustbeinstalledbyanRFprofessional.The

APantennaconnectstotheMPmodemusingareverse

polaritymaleSMAconnector.

Note: The WiFi antennas

approved for use with this device

must be of either a PCB omni

antenna with a gain of no more

than +2 dBi, or a dipole antenna

with a gain of no more than

+5dBi. No other antennas are

approved for use with this

device.

Antenna locations

WhenselectinglocationsfortheMainRF,GPS,andAP

antennas:

• Refertothedocumentationprovidedwitheachantennato

determinewhetheritrequiresagroundplane.

• EnsurethattheMainRFantennaismountedatleast20cm

(8

inches)fromvehicleoccupantsandbystanders.

• Ensurethatallradioantennas(MainRF,GPS,CBradio,

carradio)aremountedatleast20

cmormoreapart(30cm

recommended).

• Ifyouareusingreceivediversity,connectanadditionalRF

antennatothediversityantennaconnector(SMA)onthe

backoftheMP

595modem.EnsurethatthetwoRF

antennasare30to60

cm(12to24inches)apart.

• (MP595875Wonly)EnsurethattheAPantennais

mountedatleast20cmfromtheMainRFantenna.
