Viewing Images on a TV set
97
Viewing Images on a TV set
You can play back images on a television with the supplied
AV cable.
The video output signal can be switched (NTSC or PAL) to
accommodate different regional standards (p. 27). The default
setting varies between regions.
- NTSC: Japan, U.S.A., Canada, Taiwan and others
- PAL: Europe, Asia (excluding Taiwan), Oceania and others
If the video system is set incorrectly, the camera output may
not display properly.
1
Turn off the Camera and the TV.
2
Plug the ends of the AV
cable into the VIDEO IN
and AUDIO IN jacks on
the TV.
3
Connect the AV cable to
the camera station's A/V
OUT terminal ( ), set the
mode switch to (play-
back) ( ), and place the
camera securely into the
camera station ( ).
4
Turn on the TV and switch it to video mode.
5
Turn on the camera.
z
You can control the camera with the wireless controller (Basic
Guide p. 6).
VIDEO
AUDIO
IN
Yellow
Black
