CX Series Instruction Manual
Page 7
CAMERA SPECIFICATIONS
CX-EV310A-2 B&W Camera
Video Signal System EIA Standard
Image Output 1 Volt p-p/75 Ohms
Scanning System 2:1 Interlace
Resolution 380 lines horz
Sensitivity @f1.2 0.1 lux (50 IRE)
0.04 lux (30 IRE)
S/N Ratio 50dB (AGC off)
Image Sensor 1/4" Interline Transfer CCD
Pixel Size 9.60 um(H) x 7.50 um(V)
Effective Picture Elements 510(H) x 492(V)
Scanning Frequency Horz. 15.734KHz/Vert 59.9Hz
Sync System Internal / Line Lock
Gamma 0.45
AGC +12dB
Iris DC Auto Iris
Power Source DC 12V ± 1.0 volt or 24VAC
Power Consumption min 200 mA
Operating Temperature Range -30ºF to +140º F
Lens 2.8 ~ 10mm f1.2 Auto Iris
