GETTING STARTED
10 EN
MasterPage: Left
LCD Monitor/Viewfinder
Indications
During Video Recording Only
1Tape Running Indicator
(Rotates while tape is running.)
2Selected Wide Mode Indicator (੬ pg. 17)
(only 16:9 indicator is displayed)
3Recording Speed Mode (SP/LP) (੬ pg. 31)
(only LP indicator is displayed)
4Tape Remaining Time (੬ pg. 18)
5REC: (Appears during recording.)
(੬ pg. 18)
6Selected Wipe/Fader Effect Indicator
(੬ pg. 38)
7Wind Cut Indicator (੬ pg. 31)
8Time Code (੬ pg. 32)
9Digital Image Stabilizer (“DIS”) (੬ pg. 30)
(only indicator is displayed)
!SOUND 12BIT/16BIT: Sound Mode
Indicator (੬ pg. 31) (Appears for approx. 5
seconds after turning on the camcorder.)
During Both Video And D.S.C. Recording
1Battery Remaining Power Indicator
2Operation Mode (੬ pg. 20)
: Auto Mode
: Manual Mode
3LED Light Indicator (੬ pg. 34)
4 : Night-Alive Indicator (੬ pg. 38)
: Gain Up Mode (੬ pg. 31)
5Shutter Speed (੬ pg. 39)
6White Balance Indicator (੬ pg. 37)
7Selected Effect Indicator (੬ pg. 38)
8Selected Program AE Indicator (੬ pg. 38)
9Approximate Zoom Ratio (੬ pg. 19)
!Zoom Indicator (੬ pg. 19)
"Shooting Icon
(Appears and blinks during shooting.)
#Card Icon (੬ pg. 24)
: Appears during shooting.
: Blinks in white when a memory card is
not loaded.
$Image Size/Picture Quality: 640 x 480 F
(FINE) and 640 x 480 S
(STANDARD) (in order of quality)
(੬ pg. 31)
%Remaining Number Of Shots (੬ pg. 24)
(Displays the approximate remaining
number of shots that can be stored during
D.S.C. recording.)
&
: (Appears when taking Snapshot.)
(੬ pg. 24, 34)
( : Spot Exposure Control Indicator
(੬ pg. 36)
: Backlight Compensation Indicator
(੬ pg. 36)
±: Exposure Adjustment Indicator
(੬ pg. 35)
: Iris Lock Indicator (੬ pg. 36)
)Date/Time (੬ pg. 15)
~Manual Focus Adjustment Indicator
(੬ pg. 35)
LP
W
H
SOUND
12
BIT
– – –min
16:9
9
8
1
2
4
5
6
7
3
!
15:55
REC
3
10
x
M
)~
1
2
3
4
5
6
7
8
9
&
%
(
!
E
0
:
6
1
.
1
.
3
2
A
0
M
7
D
15
1
C
# $"
640
F
640
F
640
F
640
S
