User’s Manual
27
NOTE: The Privacy Mask function will be automatically disabled if the
Image Flip function is enabled, and “Masking disabled” will be
displayed on the screen.
M.E.
This option is a standard mechanical operation. As the PTZ camera tilts by
90°, it will pan 180° then continue tilting to keep tracking the object.
OFF
Select this option to disable the flip function.
NOTE: The PTZ camera will only be able to tilt 90°, or -10° ~100° with
angle adjuster adjustments.
• ZOOM SPEED
This option is used to set the zoom speed for operating the PTZ camera.
18×/26× Model:
For these models, the zoom speed options are <1> (slow) ~ <8> (fast). The
default setting is <8>.
22×/23× Model:
For these two models, the options are <FAST> and <SLOW> (default).
• SPEED BY ZOOM
If the option is set to <ON>, the pan/tilt speed will be adjusted by an internal
algorithm when zooming automatically. The larger zoom ratio results in a slower
rotation speed.
• AUTO CALIBRATION
Each PTZ camera features one horizontal and one vertical infrared light check
points. If the camera position is moved during installation or maintenance, the
relative distance between the original set point and the check point will be
changed. If the Auto Calibration function is enabled, the camera will automatically
detect this and reset the point to its original position.
• DIGITAL ZOOM
This option allows the user to enable or disable the 12× digital zoom. The
digital zoom is activated after the full optical zoom level has been reached.
NOTE: The difference between optical and digital zoom is that optical
zoom uses the lens within the camera to draw the image closer by
zooming in or out to achieve the desired effect. Optical zoom retains the full
