Grid < OSD parameters < Main Menu
!
! Opens the Grid Lines menu. This menu allows you to select and display a custom defined grid.
! See the grid tutorial in the CHDK Wiki.
! ! ! ! !
Show grid lines Enable [•] / Disable [ ]
Enables the display of custom grids.!
Load grid from file…
Displays the file selection screen. Use the directional
controls to select a grid file and press Set to select it.
!!!
! !!! ! ! ! ! ! Rulers Grid
!
! …………...Current grid.…………….! ! ! ! ! !
The name of the currently loaded grid.
Override grid colors Enable [•] / Disable [ ]
This setting will override the grid colors defined in the grid file. It will not override the
grid colors of the grid selected from the Canon menu.
Line color
Select a color for the grid lines
Fill color
Press the Set key to bring up the color selection table.
Press the Set key to select a color.
Also see:- Grids notes on page 53.
Miscellaneous Values < OSD parameters < Main Menu
!
Show misc values ! [Don’t, Always, Shoot]
•
Donʼt – Don’t show misc values on LCD.
•
Always – Always show the misc values on the LCD.!
•
Shoot – Only show the misc values when shutter is half-pressed.
Show values in video Enable [•] / Disable [ ]
Displays the Miscellaneous values when the camera is in video mode.
Show Zoom Enable [•] / Disable [ ]
Z:n/n.nx in Micscellaneous Values. Displays the current Zoom position of the lens.
Z:n = zoom position, from 1 to 14
•
Show Zoom value as [X, FL, EFL]
Method of displaying the Zoom position of the lens
X – as a multiple of the shortest focal length, as in 6X.
FL – as the actual focal length of the lens, as in 34.8mm.
EFL – as the effective focal length, (35mm Equivalent, as in 210mm.
29
