AXIS P1355 Network Camera
Set Up the Product
Set Up the Product
The Axis product can be congured by users with administrator or operator rights. To open the product’s Setup pages, click Setup in
the top right-hand corner of the Live View page.
• Administrators have unrestricted access to all settings.
• Operators have access to all settings except System Options
See also the online help
.
Basic Setup
Basic Setup provides shortcuts to the settings that should be made before using the Axis product:
1. Users. See page 49.
2. TCP/IP. See page 52.
3. Date & Time. See page 51.
4. Video Stream. See page 21.
5. Focus. See page 28
6. Audio Settings. See page 28.
The Basic Setup menu can be disabled from System Options > Security > Users.
Adjust Focus
To adjust the zoom and focus follow these instructions:
Note
• Set the focus as precise as possible with the focus puller or Focus Assistant before starting automatic ne tuning. Using the
focus puller normally gives the best result.
• The iris should always be opened to its maximum while focusing. This gives the smallest depth of eld and thus the
best conditions for correct focusing.
1. Open the product’s home page and go to Setup > Basic Setup > Focus.
2. Under the Basic tab, click Open iris. If the button is inactive the iris is already open.
3. If focus has been set before, click Reset to reset the back focus.
4. Loosen the zoom and focus pullers (see Hardware Overview on page 7 ) on the lens by turning them counter-clockwise.
Move the pullers to set zoom and focus and check the quality of the image in the image window.
If the camera is mounted so that one cannot look at the image and move the pullers at the same time, use the Focus
Assistant instead. See Focus Assistant on page 20.
5. Loosen the zoom puller and the lock screw for the focus ring (see Hardware Overview on page 7 ) on the lens by turning
them counter-clockwise. Move the zoom puller and the focus ring to set zoom and focus and check the quality of
the image in the image window.
If the camera is mounted so that you cannot look at the image and move the zoom puller and the focus ring at the same
time, use the Focus Assistant instead. See Focus Assistant on page 20.
6. Re-tighten the zoom and focus pullers.
19
