COMPRESSION STANDARDS
JPEG: A commonly used video compression scheme, also known as MJPEG. JPEG has the least impact on the camera’s processor, but it requires
the most bandwidth.
MPEG-4 (available only with 0.5 megapixel model): A full-motion video standard used by most DVD recorders. MPEG-4 is less
processor-intensive than JPEG, but it uses more bandwidth than H.264.
H.264: A new version of MPEG-4 compression used in high-definition video players such as Blu-ray
™
and HD-DVD. H.264 is the most
processor-intensive, but it requires the least amount of bandwidth.
AVAILABLE CAMERA RESOLUTION
Refer to the following table for the resolution capabilities of your camera model
Table B. Available Camera Resolution
IMAGE RATE
The image rate is the number of images per second (ips) available for the video stream configuration. Available image rates are 30, 25, 24, 15,
12.5, 12, 10, 8, 7.5, 6, 5, 4, 3, 2.5, 2, and 1.
NOTE: The maximum image rate setting might not be obtainable due to the programmed compression standard and the resolution of the stream.
Refer to the following section for more information:
• Specifications on page 67
Camera Model 0.5 Megapixel 1.3 Megapixel 3.1 Megapixel
Available
Resolutions
— — 2048 x 1536
— — 1920 x 1080
— — 1600 x 1200
— 1280 x 1024 1280 x 1024
— 1280 x 960 1280 x 960
— 1280 x 720 1280 x 720
800 x 600 800 x 600 800 x 600
704 x 576 — —
704 x 480 — —
640 x 512 640 x 512 640 x 512
640 x 480 640 x 480 640 x 480
640 x352 640 x 352 640 x 352
480 x 368 480 x 368 480 x 368
480 x 272 480 x 272 480 x 272
352 x 240 — —
352 x 288 — —
320 x 256 320 x 256 320 x 256
320 x 240 320 x 240 320 x 240
320 x 176 320 x 176 320 x 176
