TM-6710/6710CL High-Speed Progressive Scanning CCD Camera
6Appendix
6.1 Specifications
TABLE 3. Specifications Table
Imager 1/2" progressive scan interline transfer CCD with on-chip microlens
Pixels 648 (H) x 484 (V)
Pixel size 9.0 (H) x 9.0 (V) µm
Output sensitivity 12µV/e-
Micro lens Standard
Scanning 525 lines at 120Hz/60Hz
Sync output
HD =60.98KHz±5%, VD=120Hz±5% (at 50.980MHz)
HD=47.94KHz±5%, VD=96Hz±5% (at 40.068MHz) (optional)
Ext. sync input
Ext. H
D = HD output/2
HD=30.49KHz±5%, (at 50.980MHz) HD=23.97KHz±5% (at 40.068MHz)
Vertical async. reset or Vertical async. reset or
VD=120Hz±5% VD=96Hz±5%
Pixel clock 50.98 MHz / 25.49 MHz (or 40.068 MHz / 20.034 MHz (optional))
TV resolution 500 (H) x 484 (V)
Min. illumination 4 lux at normal speed (120 frame/sec.)
S/N ratio 45 dB min., AGC = off
Video output 8-bit digital output via RS-644 (8-bit x 2 dual or single channel)
Output clock: 25.49 MHz for dual channel output
Analog 1.0 Vp-p composite video, 75ohms, sync negative, non-interlace
Display mode video Analog only fHD = 30.49 KHz, fVD = 60 Hz (60 Hz mode)
AGC OFF (AGC ON is a factory option)
MGC Manual gain adjustable (6 dB to 26 dB)
Gamma 1.0 (0.45 is a factory option)
Lens mount C-mount
Power requirement 12V DC 520±50 mA (normal), 1.2A (surge)
Power cable 12P-02S (not required if camera is used with PD-12UUP)
Power supply PD-12UUP
Operating temp. - 10°C to +50°C
Vibration & Shock Vibration: 7 Grms (10Hz to 2000Hz), Shock: 70G
Dimensions 39.6mm x 46.3mm x 136.6mm (1.56" x 1.82" x 5.30")
Weight 252 grams (9.2 oz.)
