TM-6710/6710CL High-Speed Progressive Scanning CCD Camera
FIGURE 15. TM-6710 Physical Dimensions
FIGURE 16. TM-6710CL Physical Dimensions
39.6 mm
141.2 mm
1/4-20 UNC-2B
2x M6x1
PROGRESSIVE SCAN
7.0 mm
31.7 mm
2X 11.0mm
128.0 mm
46.1 mm
30.0 mm
2x M3x8
VIDEO
POWER
SHUTTER
0
1
2
3
4
5
7
8
9
DWN
UP
MODE
DIGITAL
1
0
2
3
4
5
6
7
8
9
A
B
C
D
E
6
39.6 mm
136.6 mm
1/4-20 UNC-2B
2x M6x1
PROGRESSIVE SCAN
7.0 mm
31.7 mm
2X 11.0mm
128.2 mm
46.3 mm
30.0 mm
2x M3x8
POWER
CAMERA LINK
